The Amifast T-Bar Anchor is another variation of the erection anchor and utilizes a horizontal bar running through the anchor, which results in a T-shape. The design produces higher pullout strength than related anchors and is ideal for use in back-stripping and panel rotation applications.
T-Bar Anchor
T-Bar Anchor
T-Bar Anchor
| Part Number | Safe Working Load | Safety Factor | Bar Diameter | Overall Length | Width | Thickness | Size | Lifting Clutch | Recess Former | Ult. Mech. Load | Item Wt./ea. | Box/Skid | Price (Each) | hf:att:pa_safe-working-load | hf:att:pa_overall-length | hf:att:pa_size | hf:att:pa_ult-mech-load | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PLTBA2T4 | 4000 | 4:1 | 1/2 | 4 | 1-1/4 | 3/8 | 2T | PLRC23T | PLRM2 | 16000 | .64 lbs | 30/3200 | $1.59 | 4000 | 4 | 2t | 16000 | |
| PLTBA4T414 | 5500 | 4:1 | 11/16 | 4-1/4 | 1-1/2 | 5/8 | 4T | PLRC46T | PLRM46 | 32000 | 1.18 lbs | 30/2400 | $2.74 | 5500 | 4-1-4 | 4t | 32000 | |
| PLTBA4T514 | 8000 | 4:1 | 11/16 | 5-1/4 | 1-1/2 | 5/8 | 4T | PLRC46T | PLRM46 | 32000 | 1.41 lbs | 1400/crate | $3.04 | 8000 | 5-1-4 | 4t | 32000 | |
| PLTBA4T614 | 8000 | 4:1 | 11/16 | 6-1/4 | 1-1/2 | 5/8 | 4T | PLRC46T | PLRM46 | 32000 | 1.61 lbs | 1200/crate | $3.54 | 8000 | 6-1-4 | 4t | 32000 | |
| PLTBA4T714 | 8000 | 4:1 | 11/16 | 7-1/4 | 1-1/2 | 5/8 | 4T | PLRC46T | PLRM46 | 32000 | 1.92 lbs | 20/1000 | $4.09 | 8000 | 7-1-4 | 4t | 32000 |
